Voltage: AC220-50-60 hz, 230 v
The light bulb: HMI1200W/S total power: 1500 w
Insurance: 20 a color temperature: 6500 k
Lamp holder, high temperature resistant plastic king
Size of lamps and lanterns: L500 * H760mm W410
Carton size: L620 * H900mm W605
Air box size: L610 * H910mm W480
49 kg net weight, gross weight: 62 kg
Performance characteristics
Channel: 16 control channel,
Standard DMX512 signal
Light stroboscopic/dimmer: single chip tuning,
1-10 times per second can be variable speed stroboscope
Color plate: 5 color + white light, is equipped with rainbow effect
CMYk color mixture: full CMYk color mixing is a new design of the system. Four harmonic color of lens, magenta, cyan, yellow and color temperature are in the same
A plane movement. Mechanical short distance makes color spread quickly.
Thermal protection: 130 ℃ overheating protection
Trimming: horizontal, vertical, 1.8 °
Reset: horizontal, vertical, rotary adopts photoelectric reset device, with automatic error correction function.
Horizontal rotation Angle of 450 °
Vertical rotation Angle of 270 °
Focus: linear zoom
Through external console window or lamp before body end plate control, editor of memory to run the program to the CPU inside the lamp, and no control table can also run a programming or shipment
Program, you can store the eight scenarios. Set the security password for the client, can show light bulbs and lamps and lanterns use time
